Fog cannon machine is an efficient and environmentally friendly disinfection and epidemic prevention tool, and it will play an increasingly important role in future disinfection and epidemic prevention work. At present, it has been widely used in the fields of municipal sanitation and haze control, construction site dust reduction, factory and mine construction, agricultural and forestry spraying, landscaping, fire protection, and emergency rescue.
Email: [email protected]
The water is conveyed to the atomizing nozzle of the fog gun machine through a specific pipeline by the high-pressure water pump for atomization, and then the water mist generated by the nozzle is conveyed out through the air flow generated by the air duct fan for spray. The water mist particles of the fog gun machine are extremely small, reaching the micron level, and can be used for liquid mist dust reduction, effectively controlling pollution particles, dust, etc. in the air, thereby achieving the effect of purifying the air.
Fog cannon machine is movable, loadable, fixed, and highly adaptable; Long range, large coverage area, accelerated dust settling, suppressed dust diffusion, reliable structure, stable operation, high work efficiency, remote control or fully automatic operation, flexible switching, and convenient startup.
Suitable for urban demolition sites, metallurgical and steel enterprises, mining areas, coal chemical enterprises, cement plants, thermal power plants, construction sites, open-air storage plants for materials and mineral products, concrete treatment plants, garbage dumps, garbage incineration plants, sand factories, dry material warehouses, open air blasting, and heavy dust areas.
| Model | Quiet Wind Range (m) | Water mist particle diameter (μm) | Coverage area (㎡) | Power (kw) | Pitch angle | Rotation angle | Number of nozzles | Noise at 20 meters (dB) | Weight (kg) |
| ZT-20 | 20 | 30-150 | ≤1900 | ≤3 | -5~35° | 0~340° | 12 | ≤60 | 260 |
| ZT-30 | 30 | 30-150 | ≤2700 | ≤5 | -5~35° | 0~340° | 12 | ≤65 | 290 |
| ZT-40 | 40 | 30-150 | ≤4800 | ≤13 | -5~35° | 0~340° | 24 | ≤68 | 440 |
| ZT-50 | 50 | 30-150 | ≤7600 | ≤16 | -5~35° | 0~340° | 24 | ≤68 | 530 |
| ZT-60 | 60 | 30-150 | ≤10900 | ≤21 | -5~35° | 0~340° | 30 | ≤75 | 640 |
| ZT-70 | 70 | 30-150 | ≤14900 | ≤30 | -5~35° | 0~340° | 36 | ≤75 | 850 |
| ZT-80 | 80 | 30-150 | ≤19500 | ≤37 | -5~35° | 0~340° | 46 | ≤80 | 960 |
| ZT-90 | 90 | 30-150 | ≤24700 | ≤46 | -5~35° | 0~340° | 70 | ≤80 | 1580 |
| ZT-100 | 100 | 30-150 | ≤30500 | ≤55 | -5~35° | 0~340° | 70 | ≤80 | 1610 |
| ZT-110 | 110 | 30-150 | ≤36900 | ≤68 | -5~35° | 0~340° | 100 | ≤80 | 1850 |
| ZT-120 | 120 | 30-150 | ≤43900 | ≤92 | -5~35° | 0~340° | 110 | ≤85 | 2350 |
| ZT-140 | 140 | 30-150 | ≤59800 | ≤96 | -5~35° | 0~340° | 120 | ≤90 | 2850 |
Note: The above parameters are for reference only, and the actual product shall prevail.
If the above requirements cannot meet your needs, our company can customize it according to your requirements.
