Vehicle-mounted fog cannon,widely used in coal mine, construction site demolition, roads, pesticide spraying, extermination and epidemic prevention and other environments.
Email: [email protected]
Vehicle-mounted fog cannon, fan motor can be selected according to demand between 2-7.5 kilowatts, water pump can be selected between 2-2.2 kilowatts, single ring 24 spray nozzles, static wind range between 30-40 metres, pitching using electric actuator, can reach -5-45 degrees of pitch angle, left and right rotation using geared motors, with limit switches, can be achieved by automatic pitching and rotating spraying work.
Widely used in coal mine, construction site demolition, roads, pesticide spraying, extermination and epidemic prevention and other environments.
| Model | Quiet Wind Range（m） | Water mist particle diameter（μm） | Coverage area（㎡） | Power
（kw） |
Pitch angle | Rotation angle | Number of nozzles | Noise at 20 meters （dB） | Weight（kg） |
| ZT-20 | 20 | 30-150 | ≤1900 | ≤3 | -5~35° | 0~340° | 12 | ≤60 | 260 |
| ZT-30 | 30 | 30-150 | ≤2700 | ≤5 | -5~35° | 0~340° | 12 | ≤65 | 290 |
| ZT-40 | 40 | 30-150 | ≤4800 | ≤13 | -5~35° | 0~340° | 24 | ≤68 | 440 |
| ZT-50 | 50 | 30-150 | ≤7600 | ≤16 | -5~35° | 0~340° | 24 | ≤68 | 530 |
| ZT-60 | 60 | 30-150 | ≤10900 | ≤21 | -5~35° | 0~340° | 30 | ≤75 | 640 |
| ZT-70 | 70 | 30-150 | ≤14900 | ≤30 | -5~35° | 0~340° | 36 | ≤75 | 850 |
| ZT-80 | 80 | 30-150 | ≤19500 | ≤37 | -5~35° | 0~340° | 46 | ≤80 | 960 |
| ZT-90 | 90 | 30-150 | ≤24700 | ≤46 | -5~35° | 0~340° | 70 | ≤80 | 1580 |
| ZT-100 | 100 | 30-150 | ≤30500 | ≤55 | -5~35° | 0~340° | 70 | ≤80 | 1610 |
| ZT-110 | 110 | 30-150 | ≤36900 | ≤68 | -5~35° | 0~340° | 100 | ≤80 | 1850 |
| ZT-120 | 120 | 30-150 | ≤43900 | ≤92 | -5~35° | 0~340° | 110 | ≤85 | 2350 |
| ZT-140 | 140 | 30-150 | ≤59800 | ≤96 | -5~35° | 0~340° | 120 | ≤90 | 2850 |
