Fruit Tree Pesticide Spraying with Fog Cannon Machine

Fruit Tree Pesticide Spraying with Fog Cannon Machine

In fruit tree cultivation, pest control is crucial, and pesticide spraying is key. Traditional methods are inefficient and lack uniform coverage. The fog cannon machine, with its standardized and efficient process, is now a popular choice among fruit farmers.

Precautions Before Use

(1) Equipment Check

Before use, thoroughly examine the fog cannon machine. Inspect the body for damage and ensure all connections are secure. Pay special attention to nozzles, making sure they’re unblocked. For electric models, verify the battery charge and circuit integrity. For fuel – powered ones, check the fuel level, oil circuit, and spark plug. Also, test the fan to ensure smooth operation and adjustable wind power.

(2) Pesticide Preparation

Based on pest and disease conditions, choose the right pesticides. Dilute them strictly according to the manual’s ratio. Use a clean stirrer to ensure full dissolution and even mixing. Prepare sufficient pesticides to prevent operation disruptions.

(3) Orchard Layout

Upon entering the orchard, plan the route considering tree variety, age, and density. This ensures the fog cannon machine can move freely without harming the trees. Also, note and plan around irrigation systems, poles, and other obstacles.

Standardized Operation

(1) Startup and Tuning

Start the fog cannon machine and let it run unloaded for a few minutes. Adjust the spray angle and wind power according to tree height and crown size. Lower settings for young, short trees; higher for tall, mature ones to ensure full coverage.

(2) Spraying Execution

Drive at a steady 2 – 3 km/h along the planned route. The operator should monitor the spray to ensure a fine, even mist without misses or overlaps. Slow down in areas with severe pest problems for better spraying.

(3) Safety Measures

Operators must wear protective gear like clothing, masks, and gloves to avoid pesticide contact. Set up clear warning signs in the orchard. Avoid operating in windy or rainy weather to prevent pesticide drift or wash – off, safeguarding both the environment and operator safety.

Post – operation Maintenance

(1) Equipment Cleaning

After use, empty the remaining pesticides and rinse the machine’s components, especially the nozzles, to prevent blockages. Dry the equipment with a soft cloth to avoid rust.

(2) Component Inspection

Check for loose or worn parts, especially nozzles and seals. Replace them if necessary. Lubricate power system parts and recharge batteries or refill fuel for future use.

(3) Storage

Store the clean and maintained fog cannon machine in a dry, well – ventilated place, away from sunlight and humidity. If unused for long, start it regularly to keep it in good condition.

The fog cannon machine simplifies fruit tree pesticide spraying, boosting efficiency and control. Fruit farmers who master its use can ensure healthy tree growth and a bountiful harvest.
